D3885M

( DC Motor直流馬達)

Output Power 輸出功率: 10W~34W

Weight 重量:380g(Approx.)

DC Motor – Typical Application 直流電機-典型應用

With Hall PCBA

含內置霍爾接線板

Automotive Parts: Seat Slide Rail

汽車部件：座椅滑軌

Model

型號

(DC Motor直流馬達)

Voltage(V) 電壓

No Load 空載

Rated Load 額定負載

Stall 堵轉

Operating Range

Rated

Speed (rpm)

Current (A)

Torque (mNm)

Speed (rpm)

Current (A)

Output P. (W)

Torque (mNm)

Current (A)

D3885M-S01

9~16

13.5

3551

1.020

100

2596

3.75

27.2

371

11.2

Notice: Data in this typical specification sheet are for other certain customer. Voltage, rated torque, speed, current, power and shaft extension feature & dimension can be changed to meet customer specific requirement.

注意：上述規格僅針對特定客戶，電壓、扭矩、轉速、電流、功率、輸出軸的特征和尺寸等都可以按照客戶的特殊要求進行調整。
